← Back to projects
Bachelor’s dissertation · MICS-CABG
Octopus-Inspired Soft Robotic Gripper
This final-year team project developed a low-cost, FDM 3D-printed soft robotic gripper for minimally invasive coronary artery bypass grafting. My main responsibility covered the overall mechanical design and vacuum actuation, taking the concept through CAD iterations, simulation, prototyping, testing and system integration. The final TPU 85A prototype cost approximately £0.30 in material and achieved passive adhesion, while testing also identified stiffness and pump configuration as the main areas for further development.
- Role
- Overall mechanical design and actuation
- Software / tools
- SOLIDWORKS, FDM printing, soft robotics testing
- Year
- 2025
Project media
Interactive STL model
Drag to rotate and scroll or pinch to zoom.
Project PDF
